€2,174.00
The ATAG XL70 Commercial Condensing Gas Boiler is a high-output, modulating central-heating boiler designed for commercial buildings and demanding heating installations. It has a nominal gross heat input of 68.5kW and useful heating output of up to 60.1kW at 80°C/60°C or 65.1kW at 50°C/30°C. Features include an integrated modulating pump, boiler controls, a modulating gas valve and cascade-management capability. Up to eight XL boilers can be combined in a suitably designed cascade. A correctly sized low-velocity header is required for single and cascade installations.
4
Items sold in last 24 hours
ATAG XL70 commercial boiler
The ATAG XL70 Commercial Gas Boiler is a high-output, modulating condensing boiler designed for large buildings and demanding central-heating installations. Part of the ATAG XL Commercial range, it is intended for commercial plant rooms and modular heating systems where substantial heating capacity is required.
The XL70 has a nominal gross heat input of 68.5kW, with useful heating output of up to 60.1kW at 80°C/60°C and 65.1kW at 50°C/30°C. These ratings distinguish the gas energy entering the boiler from the useful heat delivered to the heating system.
The ATAG XL Commercial range includes the XL70, XL110 and XL140 models. These boilers can operate individually or be configured into suitable cascade systems to meet higher heating demands.
Exact equipment, gas configuration, accessories and installation requirements should be confirmed against the appliance documentation and the quotation for the selected product.
The ATAG XL70’s 68.5kW rating is its nominal gross heat input, rather than the amount of useful heat delivered at every operating temperature.
| Technical rating | Output |
|---|---|
| Nominal gross heat input | 68.5kW |
| Nominal net heat input | 61.8kW |
| Useful output at 80°C flow / 60°C return | 60.1kW |
| Useful output at 50°C flow / 30°C return | 65.1kW |
| Modulating useful output at 80°C/60°C | 8.8–60.1kW |
| Modulating useful output at 50°C/30°C | Approximately 9.9–65.0kW |
These are manufacturer-published figures for the XL70. The output available in the installed system depends on operating temperatures, demand and correct commissioning.
When comparing commercial gas boilers, distinguish nominal heat input from useful heating output at the required system temperatures.
The ATAG XL70 uses condensing technology to recover heat from combustion gases. The manufacturer publishes an efficiency figure of approximately 97.3% at 80°C/60°C and 110.2% at 50°C/30°C, calculated on the net calorific-value basis.
Efficiency figures above 100% can occur when the lower heating value of the fuel is used as the calculation basis. They should not be compared directly with percentages calculated using a different basis.
Actual performance depends on flow and return temperatures, system design, gas supply, controls, commissioning and maintenance. Published efficiency figures do not guarantee a particular reduction in operating costs.
The XL70 incorporates a modulating circulation pump, modulating gas valve and boiler control equipment. ATAG’s XL Commercial documentation also describes an electronic MMI cascade controller, an automatic air vent and an electrical connection rail.
These components are designed to support integration into a properly engineered commercial heating installation. The complete system still requires suitable pipework, expansion arrangements, hydraulic design, gas supply and control configuration.
A major application of the ATAG XL Commercial range is a multiple-boiler cascade installation.
ATAG documents cascade arrangements of up to eight XL boilers, with wall-mounted or free-standing layouts available for suitable projects.
A cascade can provide higher combined heating capacity by coordinating several boilers within one designed system. The correct arrangement depends on the building’s calculated heat demand, hydraulic design, flue configuration, gas-supply capacity and required controls.
A cascade package is different from a single boiler purchase. Confirm whether the order includes an individual XL70 boiler, connection equipment, a support frame or a complete pre-packaged plant-room solution.
A correctly sized low-velocity header is required for a single ATAG XL boiler or an XL cascade installation, according to ATAG’s installation instructions.
The header separates the boiler circuit hydraulically from the wider heating installation and must be selected for the required flow rate and system configuration.
Before ordering, confirm the correct header size, system pipework, pump arrangement, temperature-sensor requirements and connection accessories with the heating-system designer.
The ATAG XL70 can be considered for appropriately designed heating installations such as:
Suitability depends on the building’s calculated heating requirement, system design temperatures, gas infrastructure and installation conditions.
The ATAG XL70 is documented as a gas-fired central-heating boiler with several compatible flue arrangements. The correct configuration depends on the appliance version, building layout, terminal location and the manufacturer’s approved installation method.
The technical documentation for the XL70 lists natural-gas specifications and identifies particular gas categories and flue configurations. Do not assume that every XL70 supplied is approved for every fuel or national market.
Before purchase, confirm:
Brand: ATAG
Product range: XL Commercial
Model: XL70
Appliance type: Condensing commercial central-heating boiler
Fuel: Natural gas, according to the referenced product listing
Nominal gross heat input: 68.5kW
Nominal net heat input: 61.8kW
Useful output at 80°C/60°C: 60.1kW
Useful output at 50°C/30°C: 65.1kW
Modulating output at 80°C/60°C: 8.8–60.1kW
Efficiency at 80°C/60°C: Approximately 97.3%, net calorific-value basis
Efficiency at 50°C/30°C: Approximately 110.2%, net calorific-value basis
Heat exchanger: Stainless steel
Circulation pump: Integral modulating pump
Controller: Integral boiler controls and cascade-management functionality
Automatic air vent: Integral
Electrical supply: 230V / 50Hz
Maximum electrical consumption: Approximately 161W
Part-load electrical consumption: Approximately 44W
Standby consumption: Approximately 2.5W
Water content: Approximately 7 litres
Maximum flow temperature: 85°C
Heating-system pressure range: 0.7–4 bar, according to the cited technical data
Empty weight: Approximately 65kg
Approximate dimensions: 1065mm high × 660mm wide × 460mm deep
Installation options: Wall-mounted or free-standing cascade arrangements
Hydraulic requirement: Correctly sized low-velocity header
These specifications are based on ATAG’s XL Commercial brochure and technical manual. Confirm the appliance identification plate and current documentation for the exact version being supplied.
The ATAG XL70 is commercial-scale gas equipment. It must be specified, installed, commissioned and maintained by appropriately qualified professionals in accordance with the manufacturer’s instructions and the applicable local regulations.
Before ordering, confirm:
The referenced ATAG installation manual covers a UK/Ireland-market version. Before supplying that version to another European country, confirm its certification, gas category, local installation requirements and service arrangements.
The ATAG XL70 is a high-output, modulating condensing gas boiler in the XL Commercial range, designed for central heating in large buildings and commercial installations.
No. Its nominal gross heat input is 68.5kW. The manufacturer lists useful heating output of up to 60.1kW at 80°C/60°C and 65.1kW at 50°C/30°C.
No. The XL70 is a commercial central-heating boiler, not an instantaneous domestic combi boiler. If domestic hot water is required, the system designer must specify a compatible external cylinder, heat exchanger or other suitable arrangement.
Yes. ATAG documents cascade configurations of up to eight XL boilers, subject to suitable hydraulic, gas-supply, flue and control design.
Yes. ATAG’s installation instructions require a correctly sized low-velocity header for single and cascade XL installations.
ATAG documents wall-mounted and free-standing cascade arrangements. The appropriate format depends on the plant-room layout and system design.
Heat input is the energy supplied by the fuel. Useful output is the heat delivered to the heating circuit. The XL70’s nominal gross heat input is 68.5kW, while its useful output depends on the system’s operating temperatures.
Not automatically. Confirm the supplied version’s certification, gas category, pressure requirements, local installation rules and service availability for the intended destination.
An appropriately qualified commercial gas-heating professional should design, install, commission and maintain the boiler and its associated gas, hydraulic, flue and electrical systems.
The ATAG XL70 is an option for commercial heating projects requiring high output, modulating operation and potential integration into a cascade system. Before ordering from EuroFuelSupply, confirm the model, availability, required header, flue components, included accessories, warranty terms and suitability for the destination country.
