Rinnai Zen 29kW Gas Combi Boiler – Natural Gas & LPG

€1,200.00

The Rinnai Zen 29kW Gas Combi Boiler is a wall-mounted condensing boiler designed to provide central heating and on-demand domestic hot water from one appliance. Available in natural-gas and LPG configurations, it features a Wi-Fi thermostat, weather compensation, an integrated condensate neutraliser and a low-NOx burner. Manufacturer specifications list up to 11.6 litres per minute of hot water at a 35°C temperature rise for the natural-gas model. Suitable indoor or outdoor installation depends on the approved configuration and manufacturer requirements.

Fuel Supplier Europe9 Items sold in last 24 hours
10 People watching this product now!

Rinnai Zen 29kW Indoor/Outdoor Condensing Gas Combi Boiler

Rinnai Zen 29kW combi boiler

The Rinnai Zen 29kW Gas Combi Boiler is a wall-mounted condensing heating appliance designed to provide central heating and domestic hot water from one compact unit. Available in natural-gas and LPG configurations, it combines heating controls, smart connectivity and on-demand hot-water production in a single appliance.

Part of the Rinnai Zen range, the Zen 29 is designed for residential properties that require a space-saving boiler with integrated heating controls. Its condensing technology, stainless steel heat exchanger, Wi-Fi thermostat and built-in weather compensation make it an option for suitable new installations and replacement projects.

The model has a rated heat input of 29kW. For natural-gas specifications, Rinnai publishes a maximum useful heating output of 28kW at an 80°C/60°C flow-and-return condition, with a maximum of 30kW at a 50°C/30°C condition.

Key Features of the Rinnai Zen 29kW Boiler

  • Rinnai Zen 29 wall-mounted condensing gas combi boiler
  • Natural-gas and LPG configurations available
  • Central heating and on-demand domestic hot water
  • Rated heat input of 29kW
  • Published maximum useful heating output of 28kW at 80°C/60°C
  • Up to 11.6L/min domestic hot-water flow at a 35°C temperature rise
  • Up to 16.3L/min at a 25°C temperature rise
  • Wi-Fi thermostat supplied as standard in the European Zen range
  • My Rinnai app connectivity and heating schedules
  • Integrated external climate probe for weather compensation
  • Stainless steel heat exchanger
  • Ultra-low-NOx metal-fibre burner
  • NOx Class 6 classification
  • Integrated condensate trap and neutraliser
  • Indoor or outdoor installation where approved
  • Built-in frost protection for the specified outdoor installation, rated by Rinnai down to −20°C
  • 60/100mm coaxial flue arrangement, with compatible alternative flue configurations available
  • European product documentation and CE certification information available from Rinnai

Features and technical values should be checked against the exact fuel variant supplied. Rinnai’s European literature confirms the principal features, dimensions and technical performance of the Zen family.

Rinnai Zen 29kW Heating Performance

The Rinnai Zen 29 is designed to provide central heating through a compatible wet heating system. Its output should be assessed against the property’s heat-loss calculation, radiator or underfloor-heating requirements and intended operating temperatures.

For the natural-gas version, Rinnai publishes the following heating figures:

  • Rated heat input: 29kW
  • Maximum useful heating output at 80°C/60°C: 28.0kW
  • Useful heating output range at 80°C/60°C: 5.3–28.0kW
  • Useful heating output range at 50°C/30°C: 5.8–30.0kW
  • Electrical supply: 230V / 50Hz

These are different measurement conditions, not contradictory ratings. The required model and design flow temperature should be established by the heating-system designer.

On-Demand Domestic Hot Water

As a combination boiler, the Rinnai Zen 29 heats domestic hot water as it is drawn, without requiring a separate domestic hot-water storage cylinder in a normal combi installation.

Rinnai’s published natural-gas specifications give these hot-water flow figures:

Temperature rise Published hot-water flow
25°C 16.3L/min
35°C 11.6L/min

A larger temperature rise generally means a lower available flow rate. Actual performance will also depend on incoming-water temperature, supply pressure and simultaneous demand.

When selecting a combi boiler, consider how many taps or showers are likely to be used simultaneously. These manufacturer figures should not be treated as guaranteed real-world flow in every installation.

Natural Gas and LPG Versions

The Rinnai Zen 29 range is available in natural-gas and LPG configurations. Selecting the correct version is essential for safe and compliant operation.

Before purchase, confirm:

  • Whether the property uses natural gas or LPG
  • The exact product variant and model reference
  • Compatibility with the site’s gas category and supply pressure
  • Whether the appliance is factory-configured for the required fuel
  • Any manufacturer-approved conversion requirements
  • Local certification and installation requirements

Do not assume that a natural-gas boiler can be connected directly to LPG without the appropriate manufacturer-approved configuration and commissioning.

Smart Wi-Fi Heating Controls

The Rinnai Zen range includes a Wi-Fi thermostat and My Rinnai app functionality for managing heating settings.

Depending on the supported configuration, the controls allow users to adjust settings, programme heating schedules and view consumption reports. The integrated climate probe supports weather compensation by helping adjust operation according to outdoor conditions.

These functions help manage comfort and heating schedules. They do not guarantee a particular saving on energy bills because consumption depends on the property, weather, occupancy, insulation and system settings.

Condensing Technology and Low-NOx Burner

The Zen 29 uses condensing technology to recover heat from combustion gases. Its stainless steel heat exchanger is designed for condensing operation, while the metal-fibre burner is specified for low-NOx combustion.

Rinnai’s published technical brochure lists an efficiency of 98.1% at 80°C/60°C and 107.9% at 50°C/30°C when calculated on the lower heating value basis. Values above 100% can appear under this calculation method; they should not be compared directly with ratings based on a different calorific-value convention.

The Zen range is listed with NOx Class 6. Actual operating performance depends on the installation, commissioning, heating temperatures, controls and maintenance.

Indoor and Outdoor Installation

Rinnai specifies that the Zen range can be installed indoors or outdoors when the correct configuration and installation requirements are followed. Its European product information lists IPX5D protection and built-in frost protection down to −20°C for the designated outdoor installation.

Outdoor installation still requires correct positioning, flue termination, drainage, clearances and compliance with local regulations. Do not treat an indoor installation as automatically suitable for outdoor use without confirming the manufacturer’s instructions for the exact model.

Compact Wall-Mounted Design

The published dimensions for the Rinnai Zen family are approximately:

  • Height: 660mm
  • Width: 440mm
  • Depth: 285mm

The exact clearance and installation envelope must also allow for pipework, flue connections and future servicing. Check the product’s installation documentation before deciding on the mounting location.

The European Zen brochure lists a 7.5-litre expansion vessel for the Zen 24 and Zen 29 models, as well as an integrated condensate trap with neutralising granules.

Technical Specifications

Brand: Rinnai
Product range: Zen
Model: Zen 29
Appliance type: Wall-mounted condensing gas combi boiler
Rated heat input: 29kW
Maximum useful heating output at 80°C/60°C: 28.0kW
Maximum useful heating output at 50°C/30°C: 30.0kW
Heating output range at 80°C/60°C: 5.3–28.0kW
Heating output range at 50°C/30°C: 5.8–30.0kW
Fuel options: Natural gas or LPG, by selected variant
Hot-water flow at 35°C rise: 11.6L/min, natural-gas specification
Hot-water flow at 25°C rise: 16.3L/min, natural-gas specification
Efficiency at 80°C/60°C: 98.1% on the manufacturer’s lower-heating-value basis
Efficiency at 50°C/30°C: 107.9% on the manufacturer’s lower-heating-value basis
NOx classification: Class 6
Electrical supply: 230V / 50Hz
Dimensions: Approximately 660 × 440 × 285mm
Expansion vessel: 7.5 litres, as listed for the Zen 29
Flue: 60/100mm coaxial configuration, with compatible alternatives
Controls: Wi-Fi thermostat and My Rinnai app functionality
Installation: Indoor or outdoor, subject to the selected configuration and local requirements

These specifications follow Rinnai’s European Zen brochure. Verify the exact LPG product fiche for values that may differ from the natural-gas version.

Installation and Safety

The Rinnai Zen 29 is a gas-fired appliance and should be installed, commissioned and serviced by appropriately qualified professionals in accordance with the manufacturer’s instructions and the regulations applicable to the installation country.

Before ordering, confirm the property’s heating demand, gas supply, hot-water requirements, flue route, condensate drainage, electrical connection, mounting location and available service support.

EuroFuelSupply serves customers across supported European markets, but gas categories, pressure requirements, certifications and installation rules can differ by country. Confirm that the selected model is approved and suitable for the intended destination before purchase.

Frequently Asked Questions

What is the Rinnai Zen 29kW combi boiler?

The Rinnai Zen 29 is a wall-mounted condensing gas combination boiler designed to supply central heating and domestic hot water from one appliance.

Is the Rinnai Zen 29 available in natural gas and LPG?

Yes. The Zen range is offered in natural-gas and LPG configurations. Select the correct product variant and confirm its fuel configuration before installation.

How much hot water does the Rinnai Zen 29 deliver?

Rinnai’s European brochure lists 11.6L/min at a 35°C temperature rise and 16.3L/min at a 25°C temperature rise for the natural-gas Zen 29. Actual delivery depends on water temperature, pressure and demand.

Does the Rinnai Zen 29 require a hot-water cylinder?

In a standard combi-boiler installation, it heats domestic hot water on demand, so a separate domestic hot-water storage cylinder is not normally required.

Does the Rinnai Zen 29 include Wi-Fi controls?

The European Zen range lists a Wi-Fi thermostat supplied as standard, with My Rinnai app functions for heating control and scheduling. Confirm the included controller with the selected product variant.

Can the Rinnai Zen 29 be installed outdoors?

Rinnai lists indoor and outdoor installation for the Zen range, with IPX5D protection and frost protection down to −20°C for the specified outdoor configuration. The installation must follow the manufacturer’s instructions and local regulations.

What is the difference between Rinnai Zen 24, 29 and 35?

These are different output models in the Zen range. Choose according to the property’s heating load and hot-water demand rather than selecting solely by the model number. Verify each model’s actual output and flow-rate specification before comparing options.

Is the Rinnai Zen 29 suitable for multiple bathrooms?

Suitability depends on simultaneous hot-water demand, incoming-water temperature, supply pressure and required outlet temperature. Use the manufacturer’s published flow data and obtain professional sizing advice before specifying the boiler.

What does the A energy rating mean?

The Rinnai Zen range is marketed with an A energy classification in its European product information. The precise rating should be confirmed against the current product fiche for the selected variant. An energy label is not a guarantee of a particular household energy bill.

Who should install the Rinnai Zen 29?

An appropriately qualified gas-heating professional should select, install, commission and maintain the appliance under the manufacturer’s instructions and the regulations in the installation country.

Buy the Rinnai Zen 29kW Gas Combi Boiler

Compare the natural-gas and LPG versions of the Rinnai Zen 29 to identify the right configuration for your heating project. Before ordering from EuroFuelSupply, confirm the exact fuel variant, included Wi-Fi controller, flue requirements, certification, warranty terms and delivery availability for your destination.
