ATAG XL70 68.5kW Commercial Condensing Boiler

€2,174.00

The ATAG XL70 68.5kW Commercial Condensing Boiler is designed for demanding central-heating installations. It features an integrated modulating pump, boiler controls and support for professionally designed cascade systems. The manufacturer specifies useful heating outputs of 60.1kW at 80/60°C and 65.1kW at 50/30°C. Confirm the exact model configuration, destination-market compatibility, current availability and delivery options before ordering.

Fuel Supplier Europe10 Items sold in last 24 hours
12 People watching this product now!

ATAG XL70 68.5kW Commercial Condensing Boiler

ATAG XL70 Commercial Boiler

The ATAG XL70 68.5kW Commercial Condensing Boiler is a natural-gas heating appliance from the ATAG XL Commercial range. Designed for commercial and larger central-heating installations, it combines condensing technology, modulating burner operation, an integrated pump and boiler control functions.

The XL70 has a nominal gross heat input of 68.5kW. Its nominal useful heating output is 60.1kW at 80/60°C and 65.1kW at 50/30°C, according to the manufacturer’s commercial boiler brochure.

The appliance can be considered for projects requiring substantial heating capacity, including selected commercial buildings, larger residential systems and professionally designed cascade installations. Final selection should be based on the building’s calculated heat demand, required flow temperatures, hydraulic design and local installation requirements.

Key Features of the ATAG XL70

  • Commercial heating capacity: 60.1kW useful output at 80/60°C and 65.1kW at 50/30°C.
  • Condensing operation: Designed to recover heat from flue gases under suitable operating conditions.
  • Modulating burner: Adjusts heat production within the manufacturer’s specified operating range.
  • Integrated modulating pump: Supports circulation through a compatible central-heating system.
  • Built-in controls: Provides boiler control functions for integration into the heating installation.
  • Cascade installation options: The XL Commercial range supports professionally designed multiple-boiler arrangements.
  • Flexible plant-room layouts: Manufacturer literature describes in-line and back-to-back configurations, including wall-mounted and free-standing arrangements.
  • Specified flue options: Flue arrangements must be selected in accordance with the appliance manual, installation design and local regulations.
  • Commercial system integration: Can be specified as part of a larger heating installation when the system design supports it.

Confirm whether the quotation covers a standalone boiler or a wider packaged system. Cascade frames, headers, pipework, flue components, controls and other accessories should not be assumed to be included unless specified.

Heating Output and Modulation

When comparing commercial boilers, distinguish between nominal heat input and useful heating output.

The ATAG XL70 has a nominal heat input of 68.5kW on a gross calorific value basis, equivalent to 61.8kW on a net calorific value basis.

The manufacturer’s brochure lists useful output of 60.1kW at 80/60°C and 65.1kW at 50/30°C. The installation documentation gives a modulation range of 8.8–60.1kW at 80/60°C and approximately 9.9–65.0kW at 50/30°C.

The small difference between the brochure’s 65.1kW nominal output and the manual’s 65.0kW upper modulation figure reflects the published values in those documents. Check the technical documentation supplied with the actual appliance for the applicable revision.

Lower-temperature operation can support condensing performance where the heating system is designed to operate at suitable flow and return temperatures. Actual performance depends on system design, controls, commissioning, maintenance and heat demand.

Efficiency and Energy Performance

The manufacturer lists the following efficiency figures for the XL70:

  • 97.3% at full load at 80/60°C, on a net calorific value basis.
  • 110.2% at low load at 50/30°C, on a net calorific value basis.
  • 109.8% at part load at 36/30°C, on a net calorific value basis.

Figures above 100% can appear when efficiency is calculated against net calorific value because that basis excludes the latent heat in water vapour. These figures do not mean the boiler creates energy, and net-basis figures should not be directly compared with gross-basis figures.

Actual energy consumption and running costs vary with the installation, operating temperatures, controls, building demand and maintenance. Avoid promising a specific percentage saving unless a substantiated comparison is available.

Potential Commercial Applications

Subject to professional heat-demand calculations and system design, the ATAG XL70 may be considered for:

  • Commercial offices and business premises
  • Hotels and hospitality facilities
  • Schools and institutional buildings
  • Warehouses and industrial facilities
  • Larger residential and multi-unit developments
  • Central-heating plant rooms
  • Projects using a suitably engineered multiple-boiler cascade

These are potential applications rather than a guarantee of suitability. A qualified heating designer should assess building heat loss, peak demand, flow rates, hydraulic separation, redundancy, flue arrangements and applicable regulations.

Cascade Systems and Plant-Room Solutions

The ATAG XL Commercial range supports cascade installations. The manufacturer’s brochure describes arrangements using up to eight boilers, with in-line and back-to-back layouts and wall-mounted or free-standing configurations.

A cascade can be considered where a project needs more combined heating output than a single boiler provides. The correct number of boilers, control strategy, headers, hydraulic arrangement and flue system must be determined by the project design and manufacturer instructions.

The range is also described for pre-packaged plant-room solutions. Confirm the contents of any package before ordering, including whether it covers the boiler units, frame, pipework, connections, controls, flue components and commissioning.

Technical Specifications About ATAG XL70 Commercial Boiler

Specification ATAG XL70
Manufacturer ATAG
Product range XL Commercial
Model XL70
Appliance type Commercial condensing central-heating boiler
Fuel in cited documentation Natural gas
Nominal heat input, gross (Hs) 68.5kW
Nominal heat input, net (Hi) 61.8kW
Useful output at 80/60°C 60.1kW
Useful output at 50/30°C 65.1kW in manufacturer brochure
Modulation range at 80/60°C 8.8–60.1kW
Modulation range at 50/30°C 9.9–65.0kW in installation manual
Full-load efficiency at 80/60°C, net basis 97.3%
Low-load efficiency at 50/30°C, net basis 110.2%
Part-load efficiency at 36/30°C, net basis 109.8%
NOx figure reported in installation documentation 34.02mg/kWh
Gas consumption for G20 under specified test conditions 6.53m³/h
Maximum electrical power consumption 161W
Electrical consumption at part load 44W
Standby electrical consumption 2.5W
Electrical supply 230V / 50Hz
Protection rating IPX4D; IPX0D for specified B23/B33 configurations
Empty weight 65kg
Mounting weight 54kg
Width 660mm
Height 1065mm
Depth 460mm
Mounting height excluding flue connection 1715mm
Central-heating water content 7 litres
Pump overrun time 2 minutes
Minimum / maximum system water pressure listed in manual 0.7 / 4 bar
Maximum flow temperature 85°C
Heat exchanger designation in manual OSS4
Gas category shown in manual II2H3P
Listed boiler flue categories B23, B33, C13, C33, C43, C53, C63, C83 and C93

Technical data is based on the cited ATAG XL Commercial brochure and XL Series installation documentation. Verify the appliance data plate, exact revision, gas configuration, flue classification, local approvals and installation requirements before purchase or installation.

Buy the ATAG XL70 from EuroFuelSupply

EuroFuelSupply supports enquiries for heating equipment for residential, trade and commercial projects across supported European destinations.

If you are sourcing the ATAG XL70 for a commercial building, heating upgrade or plant-room installation, contact our team to confirm current availability, pricing, destination compatibility and the equipment configuration required.

For trade and project quotations, please include:

  • Required quantity
  • Delivery country and location
  • Required heating output
  • Whether a cascade or packaged plant-room solution is needed
  • Known flue, control and hydraulic requirements
  • Expected project timeframe

Request a quotation: https://eurofuelsupply.com/get-a-quote/

Contact EuroFuelSupply: https://eurofuelsupply.com/contact-us/

Frequently Asked Questions

What is the output of the ATAG XL70?

The manufacturer lists useful heating output of 60.1kW at 80/60°C and 65.1kW at 50/30°C. Its nominal gross heat input is 68.5kW. These figures describe different measurements and should not be used interchangeably.

Is the ATAG XL70 suitable for commercial heating?

It belongs to ATAG’s XL Commercial range and is designed for central-heating applications requiring substantial output. A heating designer should confirm the correct capacity and system arrangement for the building.

Can the ATAG XL70 be installed in a cascade?

Yes. The XL Commercial brochure describes cascade arrangements of up to eight boilers. The final number, layout, controls, hydraulic arrangement and flue design must follow the manufacturer’s instructions and project requirements.

Does the ATAG XL70 include a hot-water cylinder?

The XL70 is a central-heating boiler, not an integrated domestic hot-water storage cylinder. Where domestic hot water is required, a compatible cylinder or other suitable hot-water arrangement must be specified separately unless the quotation explicitly includes it.

What fuel does the ATAG XL70 use?

The cited documentation lists natural gas and identifies a gas category for the documented configuration. Confirm the exact appliance data plate and local gas compatibility before purchase. Do not assume LPG conversion equipment is included.

What are the dimensions of the ATAG XL70?

The cited installation documentation lists a width of 660mm, height of 1065mm and depth of 460mm. It also lists a mounting height of 1715mm excluding the flue connection. Check the installation manual for the required clearances and access space.

What electrical supply does the XL70 require?

The manual lists a 230V / 50Hz electrical supply. Electrical installation must comply with the manufacturer’s instructions and applicable local requirements.

Can the XL70 be supplied as part of a packaged plant room?

The manufacturer describes pre-packaged plant-room solutions for the XL range. Confirm the exact package contents, boiler quantity, frame, pipework, connections, controls and flue components in the quotation.

Can I order the ATAG XL70 for delivery outside the UK?

Destination compatibility must be confirmed for the specific unit, including gas category, approvals, documentation and service arrangements. EuroFuelSupply must also confirm delivery availability and terms for the intended destination.

How do I request a trade quotation?

Contact EuroFuelSupply with the model, required quantity, delivery destination and project details. Pricing, availability, delivery and any cascade or packaged-system options must be confirmed for the specific enquiry.
