ACV E-Tech S Floor Standing Combination Electric Boiler
ACV E-Tech S electric boiler
The ACV E-Tech S is a floor-standing combination electric boiler designed to provide space heating and domestic hot water from one integrated appliance.
Using ACV’s Tank-in-Tank technology, the E-Tech S combines an electric heating system with integrated stainless steel domestic hot-water storage. This makes the range suitable for installations where heating and hot-water production need to be combined in a single floor-standing unit.
The E-Tech S range includes 160 Mono, 160 Tri, 240 Tri and 380 Tri configurations. Depending on the model, the electrical heating output is 14.4kW or 28.8kW.
Key Features
- ACV E-Tech S combination electric boiler
- Floor-standing installation
- Space heating and domestic hot water in one appliance
- ACV Tank-in-Tank technology
- Internal stainless steel domestic hot-water tank
- 14.4kW and 28.8kW heating outputs depending on model
- Single-phase and three-phase versions available
- Integral primary heating sealed-system kit
- Integrated circulating pump
- Integrated boiler controls
- Flexible heating flow and return connections
- Quiet electric operation
- No combustion flue or chimney required
- Can also operate as a standalone electric water heater
- Insulated boiler body designed to reduce standing heat losses
- Suitable for residential and commercial applications where the selected model and electrical supply are appropriate
ACV E-Tech S Models
| Model | Electrical Supply | Heating Output | Total Capacity | DHW Capacity |
|---|---|---|---|---|
| E-Tech S 160 Mono | 1 × 230V + N | 14.4kW | 167L | 99L |
| E-Tech S 160 Tri | 3 × 400V + N | 14.4kW | 167L | 99L |
| E-Tech S 240 Tri | 3 × 400V + N | 28.8kW | 250L | 164L |
| E-Tech S 380 Tri | 3 × 400V + N | 28.8kW | 394L | 263L |
ACV’s published specifications list the 160 Mono and 160 Tri models at 14.4kW, while the 240 Tri and 380 Tri models are rated at 28.8kW. The total and domestic-hot-water capacities differ by model.
Tank-in-Tank Hot Water Storage
One of the defining features of the ACV E-Tech S is its Tank-in-Tank design.
The internal stainless steel domestic hot-water tank sits within the primary heating vessel. ACV specifies domestic hot-water capacities of 99 litres for the E-Tech S 160 models, 164 litres for the E-Tech S 240 Tri and 263 litres for the E-Tech S 380 Tri.
This integrated design allows one floor-standing appliance to handle both the heating circuit and stored domestic hot water.
Electric Heating and Hot Water From One Unit
The E-Tech S is designed for projects where a combined electric heating and hot-water appliance is preferred.
ACV highlights the advantage of providing heating and hot water from one unit, helping simplify installation and reduce the space required compared with separate equipment. The boiler also includes an integral primary heating sealed-system kit and circulating pump.
Electric Boiler With No Flue
Because the E-Tech S uses electric heating rather than combustion, it does not require a conventional combustion chimney or flue.
This can offer installation flexibility in buildings where installing a combustion flue would be difficult or where an electric heating solution is preferred. ACV specifically lists no chimney/flue and quiet operation among the product features.
ACV E-Tech S Electrical Options
The E-Tech S 160 is available in both single-phase and three-phase configurations.
The E-Tech S 160 Mono uses 1 × 230V + N, while the E-Tech S 160 Tri, E-Tech S 240 Tri and E-Tech S 380 Tri use 3 × 400V + N. The selected model must therefore match the electrical infrastructure available at the installation site.
Domestic Hot Water Performance
ACV’s published data gives the following domestic-hot-water performance at 40°C:
| Model | Peak Flow / 10 min | First Hour Flow | Continuous Flow |
|---|---|---|---|
| E-Tech S 160 Mono | 356L | 700L | 413L/h |
| E-Tech S 160 Tri | 356L | 700L | 413L/h |
| E-Tech S 240 Tri | 545L | 1,234L | 827L/h |
| E-Tech S 380 Tri | 875L | 1,564L | 827L/h |
These are manufacturer test figures and should not be interpreted as guaranteed real-world consumption or outlet performance for every installation.
Heating System Specifications
The E-Tech S has a maximum operating temperature of 85°C and a maximum heating-primary service pressure of 3 bar. The domestic hot-water side is specified for a maximum service pressure of 10 bar.
The appliance includes a primary expansion vessel, circulating pump and safety/control components as part of its integrated heating arrangement.
Flexible Installation
ACV provides multiple connection arrangements for the E-Tech S range, giving installers flexibility when planning heating flow, return and domestic-hot-water connections.
The integrated controls, circulating pump and primary sealed-system equipment are designed to simplify system integration.
Suitable Applications
Depending on the selected model and system design, the ACV E-Tech S can be considered for:
- Houses
- Large residential properties
- Apartments
- Properties without mains gas
- Electric heating conversions
- Residential heating and hot-water systems
- Commercial premises
- Off-grid heating applications
- Projects requiring an integrated heating and hot-water appliance
- Installations where a combustion flue is not desirable
The correct model should always be selected according to the building heat demand, domestic-hot-water requirement and available electrical supply.
Technical Specifications
Brand: ACV
Range: E-Tech S
Type: Floor-standing combination electric boiler
Heating output: 14.4kW or 28.8kW depending on model
Technology: Tank-in-Tank
Heating: Wet central heating
DHW: Integrated domestic hot-water storage
E-Tech S 160 total capacity: 167L
E-Tech S 240 total capacity: 250L
E-Tech S 380 total capacity: 394L
Maximum operating temperature: 85°C
Maximum primary heating pressure: 3 bar
Maximum DHW pressure: 10 bar
160 Mono supply: 1 × 230V + N
160 Tri supply: 3 × 400V + N
240 Tri supply: 3 × 400V + N
380 Tri supply: 3 × 400V + N
Installation: Floor standing
Hot-water technology: Stainless steel Tank-in-Tank storage
Primary system: Integral sealed-system kit and circulating pump
E-Tech S Product Codes
Where variants are sold separately, use the exact manufacturer reference rather than one generic SKU.
- E-Tech S 160 Mono: A1002085
- E-Tech S 160 Tri: A1002084
- E-Tech S 240 Tri: A1002086
- E-Tech S 380 Tri: A1002087
ACV also publishes GTINs for these individual configurations, which can be used in structured product data when the corresponding variant is actually being sold.
Frequently Asked Questions
What is the ACV E-Tech S?
The ACV E-Tech S is a floor-standing combination electric boiler that provides space heating and domestic hot water using ACV Tank-in-Tank technology.
Is the E-Tech S an electric combi boiler?
Yes, ACV describes it as a floor-standing combination electric boiler. For technical clarity, it is an electric heating appliance with integrated Tank-in-Tank domestic-hot-water storage rather than an instantaneous gas-style combi.
What output is the ACV E-Tech S?
The range includes 14.4kW and 28.8kW heating outputs depending on the model.
What is the E-Tech S 160?
The E-Tech S 160 is the 14.4kW model family. It is available in both single-phase Mono and three-phase Tri versions and has a total vessel capacity of 167 litres, including 99 litres of domestic-hot-water capacity.
What is the E-Tech S 240?
The E-Tech S 240 Tri is a three-phase 28.8kW model with a 250-litre total capacity and 164-litre domestic-hot-water capacity.
What is the E-Tech S 380?
The E-Tech S 380 Tri is a three-phase 28.8kW model with approximately 394 litres total capacity and 263 litres of domestic-hot-water capacity. ACV’s UK site currently marks the 380 Tri as no longer manufactured, so it should only be listed as available where EuroFuelSupply has confirmed supply.
Does the E-Tech S need a flue?
No combustion flue or chimney is required because the appliance uses electric heating.
Can it provide both heating and hot water?
Yes. The E-Tech S is designed to provide space heating and domestic hot water from one integrated appliance.
Can the E-Tech S be used as a standalone water heater?
ACV states that the E-Tech S can be used as a standalone electric water heater where appropriate.
Is the E-Tech S suitable for radiators?
Yes. The appliance supplies a wet primary heating circuit and can be integrated with appropriately designed radiator heating systems. The final model selection should be based on the building’s heat requirement and system design.
Who should install an ACV E-Tech S?
Installation should be carried out by an appropriately qualified heating and electrical professional in accordance with ACV’s installation instructions and applicable local regulations.
