New
Atlas 2500BHA 2500 Litre Bunded Heating Oil Tank
2500 litre bunded heating oil tank
The Atlas 2500BHA 2500 litre bunded heating oil tank provides high-capacity storage for properties and businesses that rely on oil-fired heating or other approved fuel-storage applications. Its horizontal, double-skin design combines a primary storage tank with an outer containment layer to help manage leaks and reduce the risk of fuel escaping into the surrounding environment.
Manufactured from UV-stabilised polyethylene, the Atlas 2500BHA is designed for outdoor installation when the site, base, fuel type and local requirements are suitable. It is an option for homes, rural properties, agricultural operations and commercial premises that need a larger heating oil reserve.
Contact EuroFuelSupply to confirm availability, the correct outlet configuration and delivery arrangements for your location.
Key Features of the Atlas 2500BHA
- 2,500 litre storage capacity: Suitable for applications requiring substantial heating oil storage.
- Double-skin bunded construction: The outer tank provides secondary containment around the inner tank.
- UV-stabilised polyethylene: Designed to withstand outdoor exposure when correctly installed and maintained.
- Electronic contents monitoring: A Watchman Sonic electronic tank monitor is commonly included in the supplied equipment package; confirm the exact package before ordering.
- Overfill prevention: An overfill prevention valve helps manage filling risks.
- Inspection access: A 4-inch inspection screw lid provides access for inspection and maintenance.
- Ventilation: A 2-inch vent is specified in the product documentation.
- Outlet options: The standard configuration commonly uses a 1-inch BSP bottom outlet, with top-outlet arrangements available for selected installations.
- Lockable access cover: Helps restrict unauthorised access to the tank’s inspection area.
Confirm the final equipment list and selected outlet configuration with EuroFuelSupply before purchase.
Atlas 2500BHA Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer / model | Atlas 2500BHA |
| Tank type | Horizontal, double-skin bunded oil tank |
| Nominal storage capacity | 2,500 litres |
| Approximate capacity in UK gallons | 550 gallons |
| Material | UV-stabilised polyethylene |
| Length | Approximately 2,310 mm |
| Width | Approximately 1,550 mm |
| Height | Approximately 1,600 mm |
| Empty weight | Approximately 172 kg |
| Tank footprint | Approximately 1,840 × 1,480 mm |
| Inspection access | 4-inch inspection screw lid |
| Vent | 2-inch vent |
| Standard outlet | 1-inch BSP bottom outlet |
| Overfill prevention | Commonly supplied |
| Electronic contents gauge | Watchman Sonic commonly included in the equipment package |
| Warranty | Verify the applicable manufacturer’s warranty and terms before ordering |
Specifications are based on published Atlas 2500BHA product information. Dimensions and equipment can vary by specification or supply package. Confirm the current manufacturer’s data sheet before installation.
Benefits of a Bunded Heating Oil Storage Tank
Secondary containment for added protection
The inner tank holds the stored liquid, while the outer shell provides a secondary containment barrier. This design helps reduce the risk of an inner-tank leak releasing oil directly into the environment. It does not remove the need for inspections, suitable siting or correct installation.
Practical capacity for homes and businesses
With a nominal capacity of 2,500 litres, this tank may suit properties with substantial heating demand, rural homes, agricultural buildings and commercial premises. The appropriate capacity depends on consumption, refill arrangements, available space and the type of fuel being stored.
Outdoor-ready construction
The UV-stabilised polyethylene body is designed for outdoor storage applications. A suitable, level and load-bearing base is essential, and the tank must be installed in accordance with the manufacturer’s instructions and the rules applicable at the site.
Easier monitoring and filling management
The electronic contents monitor can help users keep track of stored fuel, while the overfill prevention equipment supports safer filling practices. These components should be checked and maintained in line with their instructions.
Suitable Applications
The Atlas 2500BHA may be considered for:
- Domestic oil-fired heating systems.
- Rural homes and larger residential properties.
- Farms and agricultural buildings.
- Estates and property-management sites.
- Commercial premises using approved heating or fuel-storage systems.
Heating oil, kerosene, diesel and HVO compatibility must be confirmed against the current manufacturer’s documentation and the intended installation. Do not assume that every liquid or fuel is suitable for this tank.
Installation and Site Preparation
Before ordering the Atlas 2500BHA, check that the installation area can accommodate the tank and allow safe access for filling, inspection and maintenance.
The tank’s approximate dimensions are 2,310 mm long, 1,550 mm wide and 1,600 mm high. Published guidance commonly recommends a base extending approximately 300 mm beyond the tank footprint on every side. The final base dimensions, construction and site clearances must be verified against the current installation instructions and applicable local regulations.
Before installation:
- Confirm the intended fuel and tank outlet arrangement.
- Prepare a level, stable and load-bearing base.
- Check access for the delivery vehicle and safe offloading.
- Verify separation distances from buildings, boundaries, drains and other relevant features.
- Arrange installation by a suitably qualified professional where required.
- Confirm all required monitoring, filling, venting and overfill-protection equipment is present.
Order the Atlas 2500BHA from EuroFuelSupply
Looking for a 2500 litre bunded heating oil tank for your property or business? EuroFuelSupply can help you enquire about the Atlas 2500BHA and confirm the specification needed for your application.
For broader purchasing requirements, explore our wholesale energy products in Europe or browse our secure storage solutions.
To confirm pricing, availability, outlet options and delivery to your destination, request a quote or contact our team through the EuroFuelSupply contact page.
Email: sales@eurofuelsupply.com
Delivery costs, lead times and destination availability must be confirmed before ordering.
Frequently Asked Questions
What is the capacity of the Atlas 2500BHA?
The Atlas 2500BHA has a nominal storage capacity of 2,500 litres, equivalent to approximately 550 UK gallons.
Is the Atlas 2500BHA a bunded oil tank?
Yes. It has a double-skin design, with an outer shell providing secondary containment around the inner storage tank.
What are the dimensions of this 2500 litre bunded heating oil tank?
Published specifications give approximate dimensions of 2,310 mm long, 1,550 mm wide and 1,600 mm high. Check the current data sheet before planning the installation.
Does the tank include an electronic contents gauge?
The standard equipment package commonly includes a Watchman Sonic electronic contents gauge. Confirm the included accessories and configuration when requesting a quote.
Can this tank store diesel or HVO?
Compatibility depends on the specific fuel grade and the manufacturer’s current guidance. Confirm suitability for diesel, HVO or any alternative fuel before ordering or filling the tank.
What warranty is provided?
Published listings differ on warranty duration. Ask EuroFuelSupply to confirm the applicable manufacturer’s warranty, conditions and registration requirements for the tank being supplied.
Can the Atlas 2500BHA be installed outdoors?
It is designed for outdoor oil-storage applications, but the installation must use a suitable base and comply with the manufacturer’s instructions and local regulations.
Do you deliver the Atlas 2500BHA across Europe?
Delivery availability, transport costs and lead times depend on the destination and current supply arrangements. Contact EuroFuelSupply with your delivery postcode or address details to request confirmation.
